Reinforcement Learning Basics

Reinforcement Learning Basics

• In reinforcement learning (RL), an agent interacts with the environment, taking actions $a$, receiving a reward $r$, and moving to a new state $s$
• The agent is tasked with maximizing the accumulated rewards or returns $R$ over time by finding optimal actions (policy)

<img src="resources/code/partA/RLbasics.gif", width="300">

## Exploration in RL - Any RL algorithm requires exploration phase to collect data for training the policy or value functions - A good exploration phase will make the learning feasible or more efficient

<img src="./exp_in_rl.JPG", width="500">

## Classic Exploration - Most are specifically designed for bandit problems, and thus, they are hard to apply in large-scale or high-dimensional problems (e.g., Atari games), resulting in increased computational demands that can be impractical - These methods heavily rely on specific assumptions about reward distributions or system dynamics, limiting their adaptability when assumptions do not hold - They may struggle in dynamic environments with complex reward structures or frequent changes, leading to suboptimal performance. However, their simplicity make them suitable for bandit setting. ## Multi-Armed Bandit Problem - In this problem, a machine with multiple arms is given. Pulling an arm results in a reward - Each machine offers a random reward based on a unique probability distribution, which is not known beforehand - The goal is to maximize the total rewards accumulated over a series of lever pulls - The multi-armed bandit problem epitomizes the exploration-exploitation tradeoff dilemma within reinforcement learning - Unlike general RL scenarios, actions chosen in bandit problems do not influence the reward distribution of the arms ## Problem Formulation - Mathematically, given reward distrbutions of the bandit arms $B=\{R_1, R_2, ..., R_k\}$, each distribution being associated with the rewards delivered by one of the ${\displaystyle K\in \mathbb {N} ^{+}}$. The agent iteratively plays one lever per round and observes the associated reward $r_t$. The objective is to maximize the sum of the collected rewards. The horizon ${\displaystyle H}$ refers to the remaining number of rounds to be played - The regret ${\displaystyle \rho }$ after ${\displaystyle T}$ rounds is defined as the expected difference between the reward sum associated with an optimal strategy (always choosing the best arm) and the sum of the collected rewards: $$ \rho=T\mu^*-\sum_{t=1}^Tr_t $$ where $\mu^*$ is the maximal reward mean ${\displaystyle \mu ^{*}=\max _{k}\{\mu _{k}\}}$ and ${\displaystyle _{t}}$ is the reward in round t - The goal can be casted to minizing the regret $\rho$

<img src="./mab.jpg", width="500">

## Implemntation of Multi-arm Bandit ### The BanditArm Class ```python # Code adapted from: https://github.com/WhatIThinkAbout/BabyRobot/tree/master/Multi_Armed_Bandits import random import numpy as np # display all floating point numbers to 3 decimal places np.set_printoptions(formatter={'float': lambda x: "{0:0.3f}".format(x)}) import pandas as pd import scipy.stats as stats import seaborn as sns import matplotlib import matplotlib.pyplot as plt from tqdm import tqdm from IPython.core.pylabtools import figsize class BanditArm: """ the base arm class """ def __init__(self, q): self.q = q # the true reward value self.initialize() # reset the arm def initialize(self): self.Q = 0 # the estimate of this arm's reward value self.n = 0 # the number of times this arm has been tried def pull(self): """ return a random amount of reward """ # the reward is a guassian distribution with unit variance around the true # value 'q' value = np.random.randn() + self.q # never allow a charge less than 0 to be returned return 0 if value < 0 else value def update(self,R): """ update this arm statistics after it has returned reward value 'R' """ # increment the number of times this arm has been tried self.n += 1 # the new estimate of the mean is calculated from the old estimate self.Q = (1 - 1.0/self.n) * self.Q + (1.0/self.n) * R def sample(self,t): """ return an estimate of the arm's reward value """ return self.Q ``` ### The ArmTester Class ```python """ Helper Functions """ # return the index of the largest value in the supplied list # - arbitrarily select between the largest values in the case of a tie # (the standard np.argmax just chooses the first value in the case of a tie) def random_argmax(value_list): """ a random tie-breaking argmax""" values = np.asarray(value_list) return np.argmax(np.random.random(values.shape) * (values==values.max())) class ArmTester(): """ create and test a set of arms over a single test run """ def __init__(self, arm_order, arm=BanditArm, multiplier=2, **kwargs ): # create arms with a mean value defined by arm order self.arms = [arm((q*multiplier)+2, **kwargs) for q in arm_order] # set the number of arms equal to the number created self.number_of_arms = len(self.arms) self.optimal_arm_index = np.argmax(arm_order) # by default a arm tester records 2 bits of information over a run self.number_of_stats = kwargs.pop('number_of_stats', 2) def initialize_run(self, number_of_steps): """ reset counters at the start of a run """ # save the number of steps over which the run will take place self.number_of_steps = number_of_steps # reset the actual number of steps that the test ran for self.total_steps = 0 # monitor the total reward obtained over the run self.total_reward = 0 # the current total reward at each timestep of the run self.total_reward_per_timestep = [] # the actual reward obtained at each timestep self.reward_per_timestep = [] # stats for each time-step # - by default records: estimate, number of trials self.arm_stats = np.zeros(shape=(number_of_steps+1, self.number_of_arms, self.number_of_stats)) # ensure that all arms are re-initialized for arm in self.arms: arm.initialize() def pull_and_update(self,arm_index): """ pull & update the specified arm and associated parameters """ # pull the chosen arm and update its mean reward value reward = self.arms[arm_index].pull() self.arms[arm_index].update(reward) # update the total reward self.total_reward += reward # store the current total reward at this timestep self.total_reward_per_timestep.append(self.total_reward) # store the reward obtained at this timestep self.reward_per_timestep.append(reward) def get_arm_stats( self, t ): """ get the current information from each arm """ arm_stats = [[arm.Q, arm.n] for arm in self.arms] return arm_stats def get_mean_reward( self ): """ the total reward averaged over the number of time steps """ return (self.total_reward/self.total_steps) def get_total_reward_per_timestep( self ): """ the cumulative total reward at each timestep of the run """ return self.total_reward_per_timestep def get_reward_per_timestep( self ): """ the actual reward obtained at each timestep of the run """ return self.reward_per_timestep def get_estimates(self): """ get the estimate of each arm's reward at each timestep of the run """ return self.arm_stats[:,:,0] def get_number_of_trials(self): """ get the number of trials of each arm at each timestep of the run """ return self.arm_stats[:,:,1] def get_arm_percentages( self ): """ get the percentage of times each arm was tried over the run """ return (self.arm_stats[:,:,1][self.total_steps]/self.total_steps) def get_optimal_arm_percentage( self ): """ get the percentage of times the optimal arm was tried """ final_trials = self.arm_stats[:,:,1][self.total_steps] return (final_trials[self.optimal_arm_index]/self.total_steps) def get_time_steps( self ): """ get the number of time steps that the test ran for """ return self.total_steps def select_arm( self, t ): """ Greedy Selection""" # choose the arm with the current highest mean reward or arbitrarily # select an arm in the case of a tie arm_index = random_argmax([arm.sample(t+1) for arm in self.arms]) return arm_index def run( self, number_of_steps, maximum_total_reward = float('inf')): """ perform a single run, over the set of arms, for the defined number of steps """ # reset the run counters self.initialize_run(number_of_steps) # loop for the specified number of time-steps for t in range(number_of_steps): # get information about all arms at the start of the time step self.arm_stats[t] = self.get_arm_stats(t) # select an arm arm_index = self.select_arm(t) # pull the chosen arm and update its mean reward value self.pull_and_update(arm_index) # test if the accumulated total reward is greater than the maximum if self.total_reward > maximum_total_reward: break # save the actual number of steps that have been run self.total_steps = t # get the stats for each arm at the end of the run self.arm_stats[t+1] = self.get_arm_stats(t+1) return self.total_steps, self.total_reward ``` ### The BanditEvironment Class ```python class BanditEvironment(): """ setup and run repeated arm tests to get the average results """ def __init__(self, arm_tester = ArmTester, number_of_tests = 1000, number_of_steps = 30, maximum_total_reward = float('inf'), **kwargs ): self.arm_tester = arm_tester self.number_of_tests = number_of_tests self.number_of_steps = number_of_steps self.maximum_total_reward = maximum_total_reward self.number_of_arms = self.arm_tester.number_of_arms def initialize_run(self): # keep track of the average values over the run self.mean_total_reward = 0. self.optimal_selected = 0. self.mean_time_steps = 0. self.arm_percentages = np.zeros(self.number_of_arms) self.estimates = np.zeros(shape=(self.number_of_steps+1,self.number_of_arms)) self.number_of_trials = np.zeros(shape=(self.number_of_steps+1,self.number_of_arms)) # the cumulative total reward per timestep self.cumulative_reward_per_timestep = np.zeros(shape=(self.number_of_steps)) # the actual reward obtained at each timestep self.reward_per_timestep = np.zeros(shape=(self.number_of_steps)) def get_mean_total_reward(self): """ the final total reward averaged over the number of timesteps """ return self.mean_total_reward def get_cumulative_reward_per_timestep(self): """ the cumulative total reward per timestep """ return self.cumulative_reward_per_timestep def get_reward_per_timestep(self): """ the mean actual reward obtained at each timestep """ return self.reward_per_timestep def get_optimal_selected(self): """ the mean times the optimal arm was selected """ return self.optimal_selected def get_arm_percentages(self): """ the mean of the percentage times each arm was selected """ return self.arm_percentages def get_estimates(self): """ per arm reward estimates """ return self.estimates def get_number_of_trials(self): """ per arm number of trials """ return self.number_of_trials def get_mean_time_steps(self): """ the average number of trials of each test """ return self.mean_time_steps def update_mean( self, current_mean, new_value, n ): """ calculate the new mean from the previous mean and the new value """ return (1 - 1.0/n) * current_mean + (1.0/n) * new_value def update_mean_array( self, current_mean, new_value, n ): """ calculate the new mean from the previous mean and the new value for an array """ new_value = np.array(new_value) # pad the new array with its last value to make sure its the same length as the original pad_length = (current_mean.shape[0] - new_value.shape[0]) if pad_length > 0: new_array = np.pad(new_value,(0,pad_length), mode='constant', constant_values=new_value[-1]) else: new_array = new_value return (1 - 1.0/n) * current_mean + (1.0/n) * new_array def record_test_stats(self,n): """ update the mean value for each statistic being tracked over a run """ # calculate the new means from the old means and the new value tester = self.arm_tester self.mean_total_reward = self.update_mean( self.mean_total_reward, tester.get_mean_reward(), n) self.optimal_selected = self.update_mean( self.optimal_selected, tester.get_optimal_arm_percentage(), n) self.arm_percentages = self.update_mean( self.arm_percentages, tester.get_arm_percentages(), n) self.mean_time_steps = self.update_mean( self.mean_time_steps, tester.get_time_steps(), n) self.cumulative_reward_per_timestep = self.update_mean_array( self.cumulative_reward_per_timestep, tester.get_total_reward_per_timestep(), n) # check if the tests are only running until a maximum reward value is reached if self.maximum_total_reward == float('inf'): self.estimates = self.update_mean_array( self.estimates, tester.get_estimates(), n) self.cumulative_reward_per_timestep = self.update_mean_array( self.cumulative_reward_per_timestep, tester.get_total_reward_per_timestep(), n) self.reward_per_timestep = self.update_mean_array( self.reward_per_timestep, tester.get_reward_per_timestep(), n) self.number_of_trials = self.update_mean_array( self.number_of_trials, tester.get_number_of_trials(), n) def run(self): """ repeat the test over a set of arms for the specified number of trials """ # do the specified number of runs for a single test self.initialize_run() for n in tqdm(range(1,self.number_of_tests+1)): # do one run of the test self.arm_tester.run( self.number_of_steps, self.maximum_total_reward ) self.record_test_stats(n) ``` ### Finally, let's define the experiment running function ```python def run_multiple_tests( tester, max_steps = 500, show_arm_percentages = True ): mean_rewards = [] number_of_tests = 500 number_of_steps = max_steps maximum_total_reward = 800 experiment = BanditEvironment(arm_tester = tester, number_of_tests = number_of_tests, number_of_steps = number_of_steps, maximum_total_reward = maximum_total_reward) experiment.run() print(f'Mean Reward per Time Step = {experiment.get_mean_total_reward():0.3f}') print(f'Optimal Arm Selected = {experiment.get_optimal_selected():0.3f}') print(f'Average Number of Trials Per Run = {experiment.get_mean_time_steps():0.3f}') if show_arm_percentages: print(f'Arm Percentages = {experiment.get_arm_percentages()}') mean_rewards.append(f"{experiment.get_mean_total_reward():0.3f}") return experiment.get_cumulative_reward_per_timestep() ``` ### Let's test the default greedy strategy ```python # create 5 arms in a fixed order ARM_ORDER = [2,1,3,5,4] MULTIPLIER = 0.1 np.random.seed(0) random.seed(0) ``` Given the order, the true values for the arms are defined by this fixed rule: ```python print([(q*MULTIPLIER) for q in ARM_ORDER]) ``` [0.2, 0.1, 0.30000000000000004, 0.5, 0.4] This mean the optimal arm is: ```python print(np.argmax([(q*MULTIPLIER)+2 for q in ARM_ORDER])) ``` 3 ```python # Greedy Selection greedy_result = run_multiple_tests(ArmTester(ARM_ORDER, BanditArm, MULTIPLIER ) ) ``` 100%|████████████████████████████████████████████████████████████████████████████████| 500/500 [00:05<00:00, 97.80it/s] Mean Reward per Time Step = 2.321 Optimal Arm Selected = 0.214 Average Number of Trials Per Run = 346.776 Arm Percentages = [0.208 0.184 0.176 0.214 0.218] ### Let's implement a better approach: $\epsilon$-greedy ```python class EpsilonGreedySelectionTester( ArmTester ): def __init__(self, arm_order, multiplier, epsilon = 0.2 ): # create a standard arm tester super().__init__(arm_order=arm_order, multiplier=multiplier) # save the probability of selecting the non-greedy action self.epsilon = epsilon def select_arm( self, t ): """ Epsilon-Greedy Arm Selection""" # probability of selecting a random arm p = np.random.random() # if the probability is less than epsilon then a random arm is chosen from the complete set if p < self.epsilon: arm_index = np.random.choice(self.number_of_arms) else: # choose the arm with the current highest mean reward or arbitrary select a arm in the case of a tie arm_index = random_argmax([arm.sample(t) for arm in self.arms]) return arm_index ``` ### Let's test $\epsilon$-greedy ```python # Epsilon Greedy _ = run_multiple_tests(EpsilonGreedySelectionTester(ARM_ORDER, MULTIPLIER, epsilon = 0.8 ) ) ``` 100%|███████████████████████████████████████████████████████████████████████████████| 500/500 [00:04<00:00, 116.50it/s] Mean Reward per Time Step = 2.336 Optimal Arm Selected = 0.275 Average Number of Trials Per Run = 343.228 Arm Percentages = [0.171 0.166 0.179 0.275 0.210] We can tune $\epsilon$ to improve the performance further. Note that: - $\epsilon=0$: Greedy Selection - $\epsilon=1$: Random Selection - Normally, a balanced $0<\epsilon<1$ will be the best ```python for e in [0.0,0.2,0.4,0.6,0.8,1.0]: print(f"---STATISTICS For Epsilon-Greedy (e={e})--") run_multiple_tests(EpsilonGreedySelectionTester(ARM_ORDER, MULTIPLIER, epsilon = e ) ) ``` 2%|█▉ | 12/500 [00:00<00:04, 106.82it/s] ---STATISTICS For Epsilon-Greedy (e=0.0)-- 100%|████████████████████████████████████████████████████████████████████████████████| 500/500 [00:05<00:00, 98.54it/s] 2%|█▌ | 10/500 [00:00<00:05, 96.80it/s] Mean Reward per Time Step = 2.308 Optimal Arm Selected = 0.196 Average Number of Trials Per Run = 348.730 Arm Percentages = [0.216 0.208 0.192 0.196 0.188] ---STATISTICS For Epsilon-Greedy (e=0.2)-- 100%|████████████████████████████████████████████████████████████████████████████████| 500/500 [00:05<00:00, 97.06it/s] 3%|██▏ | 14/500 [00:00<00:03, 122.70it/s] Mean Reward per Time Step = 2.402 Optimal Arm Selected = 0.442 Average Number of Trials Per Run = 334.058 Arm Percentages = [0.091 0.064 0.141 0.442 0.262] ---STATISTICS For Epsilon-Greedy (e=0.4)-- 100%|███████████████████████████████████████████████████████████████████████████████| 500/500 [00:04<00:00, 111.05it/s] 3%|██▍ | 15/500 [00:00<00:03, 139.33it/s] Mean Reward per Time Step = 2.385 Optimal Arm Selected = 0.400 Average Number of Trials Per Run = 336.296 Arm Percentages = [0.110 0.096 0.142 0.400 0.251] ---STATISTICS For Epsilon-Greedy (e=0.6)-- 100%|███████████████████████████████████████████████████████████████████████████████| 500/500 [00:04<00:00, 113.03it/s] 3%|██▍ | 15/500 [00:00<00:03, 136.79it/s] Mean Reward per Time Step = 2.362 Optimal Arm Selected = 0.343 Average Number of Trials Per Run = 339.462 Arm Percentages = [0.142 0.130 0.164 0.343 0.221] ---STATISTICS For Epsilon-Greedy (e=0.8)-- 100%|███████████████████████████████████████████████████████████████████████████████| 500/500 [00:04<00:00, 107.71it/s] 3%|██▍ | 15/500 [00:00<00:03, 129.87it/s] Mean Reward per Time Step = 2.334 Optimal Arm Selected = 0.266 Average Number of Trials Per Run = 343.464 Arm Percentages = [0.170 0.166 0.184 0.266 0.214] ---STATISTICS For Epsilon-Greedy (e=1.0)-- 100%|███████████████████████████████████████████████████████████████████████████████| 500/500 [00:03<00:00, 138.95it/s] Mean Reward per Time Step = 2.312 Optimal Arm Selected = 0.202 Average Number of Trials Per Run = 346.758 Arm Percentages = [0.198 0.200 0.200 0.202 0.200] As we can see, for this specific ARM_ORDER, only some $\epsilon$ show clearly better results than Greedy. They can somehow identify the best arm, indicated by a higher percentage. ```python epsilon_greedy_result = run_multiple_tests(EpsilonGreedySelectionTester(ARM_ORDER, MULTIPLIER, epsilon = 0.4 ) ) ``` 100%|███████████████████████████████████████████████████████████████████████████████| 500/500 [00:04<00:00, 100.66it/s] Mean Reward per Time Step = 2.386 Optimal Arm Selected = 0.396 Average Number of Trials Per Run = 336.164 Arm Percentages = [0.112 0.099 0.154 0.396 0.238] Now we start implementing some advanced baselines. ### The Upper Confidence Bound (UCB) Exploring Strategy ```python class UCBArm( BanditArm ): def __init__( self, q, **kwargs ): """ initialize the UCB arm """ # store the confidence level controlling exploration -- corresponding to hyperparameter c in the slides self.c = kwargs.pop('confidence_level', 2.0) # pass the true reward value to the base class super().__init__(q) def uncertainty(self, t): """ calculate the uncertainty in the estimate of this arm's mean """ return self.c * (np.sqrt(np.log(t) / self.n)) def sample(self,t): """ the UCB reward is the estimate of the mean reward plus its uncertainty """ return self.Q + self.uncertainty(t) ``` ### The Thompson Sampling Exploring Strategy Here we need to assume the reward distribution is Gaussian, which is correct in our experiment setting. ```python class GaussianThompsonArm( BanditArm ): def __init__(self, q): self.τ_0 = 0.0001 # the posterior precision self.μ_0 = 1 # the posterior mean # pass the true reward value to the base class super().__init__(q) def sample(self,t): """ return a value from the the posterior normal distribution """ return (np.random.randn() / np.sqrt(self.τ_0)) + self.μ_0 def update(self,R): """ update this arm after it has returned reward value 'R' """ # do a standard update of the estimated mean super().update(R) # update the mean and precision of the posterior self.μ_0 = ((self.τ_0 * self.μ_0) + (self.n * self.Q))/(self.τ_0 + self.n) self.τ_0 += 1 ``` ### Let's test the new methods. For UCB, we can try to tune confidence level c ```python # UCB for c in [0.0,0.2,0.4,0.6]: print(f"---STATISTICS For UCB (c={c})--") run_multiple_tests( ArmTester(ARM_ORDER, UCBArm, MULTIPLIER, confidence_level = c )) ``` 0%| | 0/500 [00:00<?, ?it/s]C:\Users\thaihung\.conda\envs\test_env\lib\site-packages\ipykernel_launcher.py:16: RuntimeWarning: invalid value encountered in double_scalars app.launch_new_instance() C:\Users\thaihung\.conda\envs\test_env\lib\site-packages\ipykernel_launcher.py:16: RuntimeWarning: divide by zero encountered in double_scalars app.launch_new_instance() 1%|█▏ | 7/500 [00:00<00:07, 64.16it/s] ---STATISTICS For UCB (c=0.0)-- 100%|████████████████████████████████████████████████████████████████████████████████| 500/500 [00:11<00:00, 42.45it/s] 1%|▉ | 6/500 [00:00<00:11, 41.87it/s] Mean Reward per Time Step = 2.213 Optimal Arm Selected = 0.000 Average Number of Trials Per Run = 362.284 Arm Percentages = [1.000 0.000 0.000 0.000 0.000] ---STATISTICS For UCB (c=0.2)-- 100%|████████████████████████████████████████████████████████████████████████████████| 500/500 [00:08<00:00, 60.29it/s] 1%|▉ | 6/500 [00:00<00:08, 54.89it/s] Mean Reward per Time Step = 2.413 Optimal Arm Selected = 0.451 Average Number of Trials Per Run = 332.876 Arm Percentages = [0.080 0.050 0.151 0.451 0.268] ---STATISTICS For UCB (c=0.4)-- 100%|████████████████████████████████████████████████████████████████████████████████| 500/500 [00:09<00:00, 55.37it/s] 2%|█▎ | 8/500 [00:00<00:06, 78.02it/s] Mean Reward per Time Step = 2.429 Optimal Arm Selected = 0.487 Average Number of Trials Per Run = 330.420 Arm Percentages = [0.062 0.032 0.158 0.487 0.262] ---STATISTICS For UCB (c=0.6)-- 100%|████████████████████████████████████████████████████████████████████████████████| 500/500 [00:08<00:00, 55.79it/s] Mean Reward per Time Step = 2.430 Optimal Arm Selected = 0.515 Average Number of Trials Per Run = 330.180 Arm Percentages = [0.058 0.037 0.117 0.515 0.274] ```python ucb_result = run_multiple_tests( ArmTester(ARM_ORDER, UCBArm, MULTIPLIER, confidence_level = 0.6 )) ``` 0%| | 0/500 [00:00<?, ?it/s]C:\Users\thaihung\.conda\envs\test_env\lib\site-packages\ipykernel_launcher.py:16: RuntimeWarning: invalid value encountered in double_scalars app.launch_new_instance() C:\Users\thaihung\.conda\envs\test_env\lib\site-packages\ipykernel_launcher.py:16: RuntimeWarning: divide by zero encountered in double_scalars app.launch_new_instance() 100%|████████████████████████████████████████████████████████████████████████████████| 500/500 [00:08<00:00, 56.85it/s] Mean Reward per Time Step = 2.422 Optimal Arm Selected = 0.491 Average Number of Trials Per Run = 331.346 Arm Percentages = [0.073 0.044 0.136 0.491 0.256] ```python # Thompson Sampling print(f"---STATISTICS For Thompson Sampling--") thompson_sampling_result = run_multiple_tests( ArmTester(ARM_ORDER, GaussianThompsonArm, MULTIPLIER )) ``` 2%|█▍ | 9/500 [00:00<00:07, 69.55it/s] ---STATISTICS For Thompson Sampling-- 100%|████████████████████████████████████████████████████████████████████████████████| 500/500 [00:07<00:00, 66.45it/s] Mean Reward per Time Step = 2.511 Optimal Arm Selected = 0.991 Average Number of Trials Per Run = 319.374 Arm Percentages = [0.000 0.001 0.001 0.991 0.007] As we can see, UCB and Thompson Sampling can easily determine the optimal arm. Reducing MULTIPLER will make the problem harder. ### Result Summary ```python test_names = ['Greedy','Epsilon Greedy','UCB','Thompson Sampling'] plt.figure(figsize=(10,8)) plt.yticks(np.arange(0., 4200, 600)) rewards = [greedy_result, epsilon_greedy_result, ucb_result, thompson_sampling_result] for test in range(len(rewards)): plt.plot(rewards[test], label = f'{test_names[test]}') plt.legend() plt.title('Mean Total Reward vs Time', fontsize=15) plt.xlabel('Time Step') plt.ylabel('Mean Total Reward') ``` Text(0, 0.5, 'Mean Total Reward')  ```python ```
